Waterproof Wireless Digital Side Rear/Around View Camera for Car/Bus/Truck/Heavy Vehicle with Night Vision
Main Features:
1) 2.4G digital signal
2) Wider viewing angle up to 120 degrees
3) CMOS 600TVL/800TVL and CCD 600TVL
4) 12V ~32V wide power supply input available
5) Wider sun visor & front speaker
6) Waterproof grade: IP66 approved
7) Night vision distance: approx. 15m
8) Day / Night sensor for automatic adjustment
Specifications:
| Model No. |
KL-CW344 |
||
|
Image Device |
1/3" CMOS |
1/3" CMOS |
1/3'' SHARP CCD |
|
TV System |
PAL / NTSC |
||
|
Effective Image Area |
4.88 mm x 3.67 mm |
4.6228 mm (H) ×3.6112 mm (V) |
-- |
|
Sync. System |
Internal |
||
|
Resolution |
800TV Lines |
600TV Lines |
600TV Lines |
|
Minimum Illumination |
0.01 Lux |
0.1 Lux (day), 0 Lux (with IR) |
0.01 Lux / F1.0, B/W: 0.001 Lux / F1.0 |
|
Electronic Exposure |
-- |
Up to 510:1 |
Up to 510:1 |
|
AGC |
Auto |
||
|
S/N Ratio |
Better than 48dB |
||
|
White Balance |
Auto |
||
|
BLC |
Auto |
||
|
Decompression form |
MPEG4 |
||
|
Power Supply |
DC12V |
DC 12-32 V |
DC 12-32 V |
|
Current Consumption |
-- |
Max. 220 mA/12V |
Max. 350 mA |
|
Operating frequency |
2400-2483.5MHz |
||
|
Vertical Sync Frequency |
50 Hz/60 Hz |
-- | -- |
|
Transmitting distance |
120M |
||
|
Transmitting speed |
12Mbps |
||
|
Emitting frequency |
17dBM |
||
|
Receiving sensitivity |
-78dBm |
-- | -- |
|
Night vision distance |
5~10m |
||
|
Lens |
f=2.8mm |
f=2.8mm |
f=2.8mm, 3.6mm |
|
Viewing Angle |
120 degree |
120 degree |
120 degree, 92 degree |
|
Operating Temperature |
-20~60 degree, RH 90% MAX. |
||
|
Storage Temperature |
-50~95 degree, RH95%MAX. |
||
|
Waterproof rating |
IP66 |
||
|
Microphone |
-- | Yes | Yes |
|
Scan Mode |
Progressive |
Progressive |
-- |
|
Image mode |
mirror/normal (optional) |
||
|
Video Output |
1.0Vp-p, 75Ohm |
||
|
Electronic Shutter |
AOTO:1/50-1/100,000 Sec. /1/60-1/100,000 Sec. |
||
|
D-WDR |
-- | -- |
ON/OFF |
|
2D-DNR |
-- | -- |
ON/OFF |
|
Back Light Comp |
-- | -- |
ON/OFF |
